GENESYS 30 – Integrated Barcode Scanner

The purpose of this product is to provide specific instructions for the following Six sections:
Section 1: Product Specifications and Product Description
Section 2: GEX B3 120 Matrix Scanner and Mount Installation to the GENESYS 30 Baseplate
Section 3: Install the GENESYS 30 Base plate inside the GENESYS 30 Sample Compartment
Section 4: Software Installation – Setting up the Matrix 120 Scanner for use with GEX DoseControl
Section 5: Troubleshooting Guide for adjusting the Focus Dial Setting of the Matrix Scanner and the Gain and Exposure Time Setup Configuration
Section 6: GENESYS 30 Cableway Lid with new cut out

The Datalogic Matrix 120 Barcode Scanner is a component of the DoseControl® Dosimetry System. It is mounted inside the GENESYS 30 Spectrophotometer sample compartment using a specially designed bracket and connected to the dosimetry workstation PC with a USB interface cable.

The device is capturing or verifying the sample ID at the time of measurement using the barcode ID for certain models of B3 Dosimeters, as part of the DoseControl® Dosimetry System. For the DoseControl® dosimetry system, the Matrix scanner feature is appropriate for 1 dosimeter/pouch (1 absorbance count) applications.
